This new, more powerful version of TRAVIS lets you observe animated waveforms propagating back and forth in transmission lines between circuit elements in this general SPICE circuit simulator. This allows one to obtain an intuitive understanding of why reflections occur in misterminated transmission lines. The enhanced schematic capture interface is now equipped with detachable tools bars, enhanced viewing capabilities, sophisticated formulas and plot options, zooming capability, full 32-bit support and more. This updated software offers you faster, more accurate simulations. This software helps you solve signal integrity problems caused by long traces on printed circuit boards (PCB); identify the effects of terminations and diode clamps on reflections on PCBs or ICs; observe resonant behavior in complicated transmission line networks; and determine the potential for electric and magnetic cross talk in coupled transmission lines. This updated version gives you the ability to...
