The diminishing size and greater complexity of modern semiconductor integrated circuits poses new challenges in fault detection. Photon Emission Microscopy (PEM) is a physical fault localisation technique used for analysing IC failures. Detailing the PEM technique and its application to semiconductor device analysis, this unique reference: Illustrates the application of the PEM technique in various areas of device reliability, in particular hot-carrier, oxide and ESD reliability. Presents the principles of design and calibration for a spectroscopic emission microscope system along with coverage of the three main operation modes: frontside, backside and spectroscopic PEM. Provides an analysis of light emission in semiconductors under hot-carrier and high-field impulse stressing in MOS transistors and photon emission from biased MOS capacitors. Not only an essential reference for researchers and students in the field, the numerous...
