I/O bandwidth in the Multi-Tb/s range is required for current and future high performance VLSI chips. This trend demands high-speed, high-density and low power I/Os. AC coupled interconnect (ACCI) has been demonstrated as a systematic solution for providing higher pin density and lower power dissipation. ACCI utilizes non-contact capacitor plates as signal I/O which yields a much higher pin density than traditional solder bump I/O. ACCI saves significant power with pulse signaling. A test-chip with a complete capacitively coupled serial link is designed including: multi-phase DLL, serializer, transmitter, pulse receiver, clock and data recovery and deserializer. A 3Gb/s ACCI chip-to-chip communication is demonstrated through two 150fF coupling capacitors and a 15 cm microstrip line. A fully differential pulse receiver design is also demonstrated with 6-bit bus running at an aggregate bandwidth of 36Gb/s. Signal integrity issues associated with the ACCI bus, such as crosstalk and...
