The control unit is one of the most important parts of any digital system. As a rule, control units have an irregular structure, which makes the processing of their logic circuits design very sophisticated. One possible way to optimise such characteristic as the size or performance of control units is to adapt their structures to the particular properties of interpreted control algorithms. In this book control algorithms are represented by the linear graph-schemes of algorithms (GSA), where the number of perator vertices is not less than 75% of the total number of all algorithm vertices. A special class of control units named as compositional microprogram control units (CMCU) is proposed as the best way for interpretation of linear control algorithms. TheCMCU includes a finite state machine, which addresses microinstructions of interpreted microprogram, and a microprogram control unit including control memory, which keeps only microoperations of initial GSA. The microprogram control...
